Handling the camera10
10.12 Assigning functions to the programmable
button
10.12.1 General
You can assign different functions to the programmable button
. You can, for example,
use the programmable button to easily switch between two settings you use often. You
can also choose to define two different setups for saving and previewing: the ordinary set-
up for the trigger (which is defined by the Save options and storage settings, see section
24.1.4 Save options & storage, page 100) and another setup for the programmable button.
Available options for the programmable button:
• No action: This is the default setting. Nothing will happen when you push the button.
• Switch Auto <> Manual temperature scale: Switch between automatic or manual image
adjustment mode. For more information, see section 13.3 Adjusting the infrared image,
page 60.
• Autofocus: One-shot autofocus of the infrared camera.
• Continuous autofocus: Switch between the enabled/disabled continuous autofocus
functions.
• Hide image overlay graphics: Switch between hide/show all overlay graphics and image
overlay information. For more information, see section 13.8 Hiding all overlay, page 65.
• Calibrate: Perform a manual NUC. For more information, see section 13.7 Performing a
non-uniformity correction (NUC), page 65.
• Auto-adjust the manual temperature scale: Perform an automatic adjustment of the im-
age while remaining in manual image adjustment mode.
• Switch Thermal <> Digital camera: Switch between the image modes Thermal and Digi-
tal camera. For more information, see section 14 Working with image modes, page 67.
• Switch Thermal <> Thermal MSX: Switch between the image modes Thermal and Ther-
mal MSX. For more information, see section 14 Working with image modes, page 67.
• Switch 1x zoom <> Max zoom: Switch between the digital zoom factor of 1× and maxi-
mum zoom.
• Switch camera flash On <> Off: Switch between the enabled/disabled camera flash
functions. For more information, see section 10.13 Using the camera lamp as a flash,
page 38.
Note The flash function will not be activated if the setting Lamp & laser is set to the
option Disable all. For more information, see section 24.1.5 Device settings, page 100.
• Switch single shot <> Video: Switch between the recording modes Single shot and
Video.
• Switch between two latest palettes: Switch between the two last-used color palettes.
For more information, see section 13.5 Changing the color palettes, page 63.
• Switch temperature range: Cycle through the camera temperature ranges. For more in-
formation, see section 24.1.3 Camera temperature range, page 99.
• Switch screen rotation On <> Off: Switch between enabled/disabled screen rotation.
• Save: Save an image.
• Save + Prompt for note: Save an image and display the note annotation tool.
• Save + Prompt for table: Save an image and display the table annotation tool.
• Save + Prompt for voice annotation: Save an image and display the voice annotation
tool.
• Save + Prompt for sketch: Save an image and display the sketch annotation tool.
• Save + Select annotation from menu: Save an image and display the annotation tool
menu.
• Preview: Display a preview image.
• Preview + Prompt for note: Display a preview image and the note annotation tool.
• Preview + Prompt for table: Display a preview image and the table annotation tool.
#T810190; r. AI/41890/41890; en-US
37
