Handling the camera10

10.14.2 Mounting the hand strap

Follow this procedure:

1. Fit the upper part of the hand strap into the bracket.

2. Fit the bracket in place on the camera and tighten the screw with the supplied Torx key.

#T810190; r. AI/41890/41890; en-US
