Annotating images17
No action
<Severity>
Critical
Non-critical
<Severity>
17.4 Adding a voice annotation
17.4.1 General
A voice annotation is an audio recording that is saved to the infrared image file. The re-
cording can be played back in the camera, and in image analysis and reporting software
from FLIR Systems.
The voice annotation is recorded using the built-in microphone. You can also use a Blue-
tooth-enabled headset. For information on how to pair a headset with the camera, see
section 21 Pairing Bluetooth devices, page 94.
17.4.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the navigation pad to display the top toolbar.
3. On the top toolbar, select the
icon and push the navigation pad.
4. On the right toolbar, select the
icon and push the navigation pad.
5. A context menu is displayed.
6. To start a recording, select
(Record) and push the navigation pad.
7. To stop the recording, select
(Stop) and push the navigation pad.
8. To listen to the recording, select
(Play) and push the navigation pad.
9. To delete the recording, select
(Delete) and push the navigation pad.
10. When completed, select
(Done) and push the navigation pad.
#T810190; r. AI/41890/41890; en-US
87
