FUSE BOX LOCATIONS

Engine Compartment Fuse Box

The fuse box is located in the engine

compartment. See Maintenance (page

177).

Passenger Compartment Fuse Box

E159113

The fuse box is located below the glove

box.

Luggage Compartment Fuse Box

E163779

The fuse box is located in the luggage

compartment on the right-hand side.

Remove the fuse box cover to gain access

to the fuses.

166
