• Check brake pedal operation. Drive

your vehicle 15 feet (4.5 meters) back

and forth to remove rust build-up.

• Check fluid levels (including coolant,

oil and gas) to make sure there are no

leaks, and fluids are at recommended

levels.

• If the battery was removed, clean the

battery cable ends and inspect.

Contact your authorized dealer if you have

any concerns or issues.

208
