Passenger Compartment Fuse Box

E129926

Circuits protectedFuse RatingFuse

Fuel pump20AF56

Not used-F57

Not used-F58

Passive anti-theft system transceiver5AF59

Interior lamp10AF60

Driver door switch pack

Glove compartment lamp

171
