Drivebelt Routing

E161383

A. Long drivebelt is closest to the engine

B. Short drivebelt is farthest from the

engine

MOTORCRAFT PARTS - 1.6L

Part NumberComponent

FA-1908

Air filter element

FL-910S

Oil filter

SP-532

Spark plugs

FP-70 (front)Cabin air filter

FP-75 (auxiliary AC)

WW-2954 (driver side)Windshield wiper blade

237

Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, Edition date: 07/2013

Capacities and Specifications
