TRANSMISSION CODE

DESIGNATION

E142806

The transmission code is on the Safety

Compliance Certification Label. The

following table shows the transmission

code along with the transmission

description.

DescriptionCode

Six-speed automatic trans-

mission 6R80

241

Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, Edition date: 07/2013

Capacities and Specifications
