CHILD SAFETY LOCKS

WARNING

You cannot open the doors from

inside if you have put the child safety

locks on.

E169581

The childproof locks are located on the

rear edge of each rear door and must be

set separately for each door.

Left-Hand Side

Turn counterclockwise to lock and

clockwise to unlock.

Right-Hand Side

Turn clockwise to lock and

counterclockwise to unlock.

Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, Edition date: 07/2013
