• Engine coolant temperature
gauge (if enabled): Indicates
engine coolant temperature. At
normal operating temperature,
the level indicator will be in the
normal range. The indicator will
change colors indicating blue for
cool, gray for normal and red for
hot. If the engine coolant
temperature exceeds the normal
range, stop the vehicle as soon as
safely possible, switch off the engine and let then engine cool.
The engine coolant temperature gauge can be enabled or disabled. See
Base message center in this chapter for information on changing the
display settings.
• 4WD gauge (if equipped and
enabled): Indicates 4WD status.
See Four wheel drive (4wd)
system in the Driving chapter for
information.
3. Speedometer: Indicates the current vehicle speed.
4. Fuel gauge: Indicates approximately how much fuel is left in the fuel
tank (when the ignition is in the on position). The fuel gauge may vary
slightly when the vehicle is in motion or on a grade. The fuel icon and
arrow indicates which side of the vehicle the fuel filler door is located.
H
C
Instrument Cluster
22
2011 Explorer (exp)
Owners Guide, 3rd Printing
USA (fus)
