5. Disconnect the electrical
connector (1) from the lamp
assembly. Disconnect the bulb
socket (2) from the lamp assembly
by squeezing the two tabs at the top
and bottom of the socket.
6. Pull bulb straight out of socket and install the new bulb.
7. Install the bulb socket (2) by pushing it directly into the lamp
assembly until the top and bottom tabs snap into place. Reconnect the
electrical connector
8. Carefully install the tail lamp assembly on the vehicle by securing the
lamp assembly with two bolts.
Replacing tail/brake lamp bulbs
For bulb replacement, see your authorized dealer.
Replacing fog lamp bulbs
1. Make sure the headlamp switch is
off.
2. Remove the bulb socket from the
fog lamp by turning it
counterclockwise.
3. Disconnect the electrical
connector.
Reverse steps to reinstall bulb(s).
2
1
Lights
89
2011 Explorer (exp)
Owners Guide, 3rd Printing
USA (fus)
