4. Remove the wing bolt that
secures the jack kit by turning it
counterclockwise.
5. Remove the jack kit which
includes jack (4), wheel wrench (lug
wrench) (3), wheel chock (5),
L-shaped bolt (1) and tow recovery
hook (2).
6. Remove the jack, wrench and
wheel chock from the foam tray.
7. Turn the lead screw (where the
lug wrench attaches) of the jack by
hand to release the wheel wrench
from the jack. Press the button on
the wrench to extend the handle.
Fold down the wrench socket.
Tire change procedure
WARNING: When one of the front wheels is off the ground, the
transaxle alone will not prevent the vehicle from moving or
slipping off the jack, even if the vehicle is in P (Park).
2
5
4
3
1
Roadside Emergencies
340
2011 Explorer (exp)
Owners Guide, 3rd Printing
USA (fus)
