Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
45 5A Not used (spare)
46 10A Climate control module
47 15A Fog lamps, left and right turn
signal mirror feed
48 30A Circuit
Breaker
Rear power windows, Passenger
power window, One touch down
(driver side only)
49 Delayed
accessory relay
Body control module
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
WARNING: Always disconnect the battery before servicing high
current fuses.
WARNING: To reduce risk of electrical shock, always replace
the cover to the power distribution box before reconnecting the
battery or refilling fluid reservoirs.
If the battery has been disconnected and reconnected, refer to the
Battery section of the Maintenance and Specifications chapter.
Roadside Emergencies
331
2011 Explorer (exp)
Owners Guide, 3rd Printing
USA (fus)
