Optional cluster
Shown in standard measure. Metric similar.
1. Multifunction display: This displays the fuel gauge, tachometer,
engine coolant temperature, odometer/trip meter and other vehicle
features. This is also used to configure different vehicle personalization
options and display the status of various vehicle functions. See Uplevel
message center in this chapter for more information.
2. Speedometer: Indicates the current vehicle speed.
3. Infotainment display: This display is used for the entertainment,
phone, navigation and climate systems. See the MyFord Touch
supplement for more information.
BASE MESSAGE CENTER (IF EQUIPPED)
WARNING: Driving while distracted can result in loss of vehicle
control, accident and injury. Ford strongly recommends that
drivers use extreme caution when using any device or feature that may
take their focus off the road. Your primary responsibility is the safe
operation of the vehicle. We recommend against the use of any
handheld device while driving and that you comply with all applicable
laws.
1 3
2
km/h
20
0
40
60
80
100
120
140
160
180
200
80
60
40
20
0
100
120
140
MPH
Instrument Cluster
23
2011 Explorer (exp)
Owners Guide, 3rd Printing
USA (fus)
