12-volt socket
The sockets also work when the ignition is
switched o → .
Using elec
trical appliances with the engine
switched o and the ignition switched on
will drain the battery.
To avoid damage caused by voltage fluctu-
ations, switch o connected electrical
equipment before switching the ignition on
or o and before starting the engine.
12-volt sockets can be found in the follow-
ing locations in the vehicle:
— Stowage compartment in the dash panel
→ page 12.
— Centre console → page 13.
— In the luggage compartment or in front of
the third row of seats.
230-volt socket with earthing contact
The 230-volt socket with earthing contact
can be found in the following locations in
the vehicle → Fig. 144:
— On the partition between the passenger
area and luggage compartment.
— On the rear centre console.
The socket is activated automatically as
soon as a plug is connected when the en-
gine is running. If there is sucient energy in
the system, the socket can also be used
when the engine is o →
.
C
onnecting electrical equipment
1. Open the cover and insert the plug all
the wa
y into the socket to release the
integrated child socket protection.
Electricity will not flow until the child sock-
et protection has been unlocked.
LED display on the socket:
The child lock is
disengaged. The socket is ready for
use.
The ignition is
switched o but there is sucient en-
ergy available to continue to supply
the socket with power for up to 10
minutes. If you remove the plug dur-
ing this time, the socket switches o
and cannot be used again until the ig-
nition is switched back on.
Constant green light
Flashing green light:
There is a malfunction
such a
s a shuto due to excess cur-
rent or temperature.
Temperature switch-o
The inverter in the 230-volt socket with
earthing contact will switch o automati-
cally if the temperature exceeds a specific
value. The switch-o function prevents the
connected device from overheating when
the power consumption is too high or if the
ambient temperature is too high. The 230-
volt socket with earthing contact cannot be
used again until aer the cool-down phase.
To use the 230-volt socket again aer the
cool-down phase, disconnect the plug of
a connected device and then plug it in
again. This helps prevent the connected
electrical devices being switched on acci-
dentally.
DANGER
High voltage in the electrical system!
·
Do not spill any liquids over the sockets.
·
Do not plug any a
dapters or extension
cables into the 230-volt socket with
earthing contact. Otherwise the built-in
child lock will disengage and power will
be supplied to the socket.
·
Never insert any items made of con-
ducting materials, e.g. knitting needles,
into the contacts of the 230-volt socket
with earthing contact.
NOTICE
·
Ob
serve the operating instructions of the
connected devices!
·
12-volt socket:
— Never exceed the maximum power rat-
ing as this could damage the whole ve-
hicle electrical system.
— Only use accessories that have been
approved in accordance with the appli-
cable electromagnetic compatibility
guidelines.
— Never feed electricity into the socket.
·
230-volt socket with earthing con-
tact:
Flashing red light
212
Practical equipment
