1. Guide the pre-tensioned removable ball
c
oupling into the mounting tube from
below.
2. Push the ball coupling firmly upwards
until it engages. Both centring devices
→ Fig. 157
5 must engage in the
mounting points on the vehicle.
3.
T
he handwheel → Fig. 157
9 has now
returned to its original position. T
here is
no longer a gap between the hand-
wheel and the ball coupling.
4.
Turn the key → Fig. 157
8 in the hand-
wheel clockwise and remove it.
5.
T
he handwheel → Fig. 157
9 may now
no longer be pulled out.
6
.
Fit the lock cap → Fig. 157
7 on the lock
and pla
ce the key in the stowage box.
7. Secure the stowage box under the
right-hand front seat.
Step 4: Safety check.
Before hitching a trailer, check that the ball
coupling is secured correctly.
1.
The green marking → Fig. 157
12 on the
handwheel must point towards the
white marking on the b
all coupling
11 .
2.
T
he handwheel → Fig. 157
9 must rest
on the b
all coupling and there must be
no gap between them.
3. Shake or pull down on the ball coupling
→ Fig. 157 with some force. It must sit
firmly in the mounting →
.
4
. The lock must be locked and the
key → Fig. 157
8 removed.
5.
T
he lock cover → Fig. 157
7 must cover
the lock in the handwheel.
WARNING
Improper use of the towing bracket can
c
ause injury and accidents.
·
Only use the ball coupling when it is se-
cured correctly.
·
Never use the towing bracket if the
smallest diameter of the ball → Fig. 157
2 is less than 49 mm.
·
T
he ball coupling is heavy. When per-
forming the safety check, the ball cou-
pling could fall o and c
ause crush inju-
ries.
·
Do not touch the handwheel when the
ball coupling is pre-tensioned. When
the ball coupling is pressed into the
mounting, the handwheel will jump
back to its original position.
·
If the ball coupling cannot be attached,
have the towing bracket checked by
a qualified workshop.
·
Never use the towing bracket if the ball
coupling does not engage properly or
cannot be pre-tensioned.
·
Never use the ball coupling if the key in
the handwheel cannot be removed
when the ball coupling is fitted. This
means that the ball coupling is not
locked properly.
·
Always stow and secure the removed
ball coupling in the storage box under
the front right seat.
NOTICE
·
T
he mounting on the vehicle, handwheel,
shank and retaining balls of the ball cou-
pling must all be clean and undamaged.
Otherwise you may not be able to lock
the ball coupling securely.
·
Do not aim a high-pressure cleaner or
steam cleaner directly at the ball cou-
pling mounting. This could wash the
grease required for lubrication out of the
mounting.
NOTICE
The removable ball coupling is required for
towing. Make sure you alwa
ys carry the ball
coupling in the vehicle → page 307.
Towing bracket 269
2KF012720AB
