Edge Erase (Erasing Edges and Margin Shadows in the Document)
When you scan a document with the document cover open or when you scan a book, the
edges and center margin of the document may be scanned as black shadows. The Edge
Erase feature allows you to erase such shadows.
Note • For 2-sided originals, the same edge erase amounts are set for the front and back sides.
• If you set [Reduce/Enlarge], the edge erase amounts will be reduced or enlarged in proportion to the
ratio you specified.
1 Select [Edge Erase].
2 Select any option.
3 If you select [Parallel Edges], use [+] and [-] to specify the erase widths of top and bottom,
left and right, and center of the document.
4 Select [Original Orientation].
îš„ All Edges
The edge width to erase is set to 2 mm for the top and bottom, and left and right edges.
îš„ Parallel Edges
Allows you to specify the edge erase amounts.
z
Top & Bottom
Erases the shadows of top and bottom edges of the document according to the
orientation of the loaded document. You can specify the edge width to erase in the range
from 0 to 50 mm in 1 mm increments.
z
Left & Right
Erases the shadows of left and right edges of the document according to the orientation
of the loaded document. You can specify the edge width to erase in the range from 0 to
50 mm in 1 mm increments.
z
Center
Erases the shadow in the center of facing pages of a bound document. You can specify
the center erase width in the range from 0 to 50 mm in 1 mm increments.
To Next Page
