6.1 Clearing Paper Jams 107
5. Close the front cover.
Important
• Do not use excessive force on the tray. Doing so could damage the tray or the inside of the printer.
Paper Jams at the Duplex Unit
1. Press the side button and open the front
cover.
2. Carefully pull out the jammed paper from
the Duplex Unit. If jammed paper cannot be
found, go to the next step.
3. Grasp the knobs of the transfer belt unit as
shown in the illustration on the right and
open the unit fully.
4. Remove the jammed paper. Confirm that
there are no scraps of paper left inside the
transfer belt unit.
To Next Page
