2.1 Main Components and Functions 37
Control Panel
No. Name Description
1 LCD display Displays the setting items, printer status, and messages.
Refer to
• "Control Panel Display" (P. 38)
2 <Menu> button Press to display the menu on the control panel display.
3 <Eject/Set> button Press to apply the value entered or the setting selected. Use this button to print
a report/list.
4 <Energy Saver> indicator/
button
Lights up in the Sleep mode. Push this button to exit the sleep mode.
5 <Cancel Job> button Press to cancel printing.
6
< > < > < > < > buttons
Press the arrow buttons to move to a setting, value or another menu.
To use the Secure/Sample Print feature, use the < > button.
Note
• Holding down the < > button or the < > button successively increases or
decreases the value, respectively. To display the default setting, press the
< > button and the < > button simultaneously.
• To use the Secure/Sample Print feature, the additional memory (optional)
must be installed.
7 <Error> indicator Lights up when an error is detected in the printer.
8 <Ready> indicator Lights up when the printer is ready to receive a job from a computer.
12 34
5678
To Next Page
