Fujitsu LIFEBOOK E781 User Manual

Working with the notebook
2
1
► Position the notebook so that it is in line with the back edge and positioning
aid of the Port Replicator (1).
► Push the notebook o
nto the Port Replicator in the direction of the arrow (2) until it engages.
Connecting the mains adapter to the Port Replicator
1
2
3
► Connect the mains adap ter cable to the DC
jack (DC IN) of the Port Replica tor (1).
► Connect the power cable to the
mains adapter (2).
► Plug the power cable into the mains
socket (3).
When th e notebook is conne cted to a Port Replicator, the operating system creates
a hardw are profile for the "Docked" mode. In this profile, for example, the setting is
saved a s to which monitor was last used for outpu t. This profile will be loaded, as
soon as the notebook is connected to a Port Replicator of the same type.
52 Fujitsu Technology Solutions

Fujitsu LIFEBOOK E781 Specifications

General

Brand	Fujitsu
Model	LIFEBOOK E781
Category	Laptop
Language	English
