Connecting external devices
Connecting an external m onitor
An analogue monitor is connected to the ana logue VGA monitor port, a digital monitor to
the DisplayPort. Screen output is limited to a ma ximum of two monitors at any one time
(see "
Key combinations", Page 26, section "Toggle output scre en").
MonitorVGAcon nectionsocketMonitorportMonitorp ort
Digital DisplayPort
Analogue V GA monitor port
► Switch off the note
book a nd the external monitor.
► Plug the data cable of the external monitor into the monitor po rt.
► First switch on th
e exte rnal monitor and then the notebook.
You can also swi
tch between the external monitor and the LCD monitor of the
notebook, see c
hapter "
Key combinat ions", Page 26.
You can displa
y the same picture on the external monitor and the
notebook LCD m
onitor simultaneously.
Fujitsu Technology Solutions 65
