Table 4-57
System-Stopped/Cold Replacement Procedure of the HDD/SSD (continued)
Work
Order
Task Reference
4 Stopping all physical partitions "9.5.2 Stopping All Physical Partitions"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6Removing the power cords of all the
SPARC M12-2/M12-2S units
"9.8.2 Removing the Power Cords"
7Removing the HDD/SSD from the
SPARC M12-2/M12-2S
"15.3.1 Removing an HDD/SSD"
8 Installing an HDD/SSD
in the SPARC
M12-2/M12-2S
"15.4.1 Installing an HDD/SSD"
9 Installing the power cords on all the
SPARC M12-2/M12-2S units
"10.1.1 Installing a Power Cord"
10 Diagnosing all the SPARC M12-2/M12-2S
units
"10.5.1 Diagnosing the SPARC M12
Hardware"
11 Confirming that there is no problem with
the replacement HDD/SSD
"10.5.3 Checking the FRU Status After
Maintenance"
12 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
13 Powering on the physical partitions "10.9.1 Starting the System With an
XSCF Command"
14 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Table 4-58
System-Stopped/Cold Replacement Procedure of the HDDBPU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the HDDBPU to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2/M12-2S that houses the
HDDBPU to be replaced
"8.1.2 Checking Hardware"
4 Stopping all physical partitions "9.5.2 Stopping All Physical
Partitions"
4.6.7 System-Stopped/Cold Replacement Workflow of
the HDDBPU
Table 4-58 shows the workflow for system-stopped/cold replacement of the HDDBPU.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023138
