Fujitsu Oracle SPARC M12-2 User Manual

Table 5-13
Inactive/Cold Addition Procedure of a PCIe Card (continued)
Work
Order
Task Reference
8 Installing the power cords on the SPARC
M12-2S with the added PCIe card, and
incorporating it into the building block
configuration
"10.1.1 Installing a Power Cord"
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
9 Diagnosing the SPARC M12-2S with the
added PCIe card
"10.5.1 Diagnosing the SPARC M12
Hardware"
10 Confirming that there is no problem with
the added PCIe card
"10.5.3 Checking the FRU Status After
Maintenance"
11 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
12 Powering on the physical partition of the
added PCIe card
"10.9.1 Starting the System With an
XSCF Command"
13 Assigning
the I/O resource to a logical
domain
"3.2 Operations and Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
Table 5-14
Inactive/Cold Addition Procedure of the HDD/SSD
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Powering off the physical partition
containing the SPARC M12-2S requiring
maintenance
"9.5.1 Stopping a Specific Physical
Partition"
3 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
4 Releasing the SPARC
M12-2S requiring
maintenance from the building block
configuration, and removing the power
cords
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
"9.8.2 Removing the Power Cords"
5.4.2 Inactive/Cold Addition Workflow of the HDD/SSD
You can perform inactive/cold addition of the HDD/SSD in the following configuration:
■
Building block configuration where two or more physical partitions are operating
Before adding the HDD/SSD, see "Precautions for HDD/SSD addition" in "7.2
Precautions for FRU Expansion."
Table 5-14 shows the workflow for inactive/cold addition of the HDD/SSD.
Chapter 5 FRU Addition Workflows 169
