190-00207-02 GTX 330/330D Installation Manual
Rev. U Page 2-1
2 INSTALLATION OVERVIEW
2.1 Introduction
This section provides hardware equipment information for installing the GTX 330 Mode S Transponder,
related hardware and optional accessories. Installation of the GTX 330 should follow the data detailed in
this manual. Cabling is fabricated by the installing agency to fit each particular aircraft. The installation
should follow the guidance of FAA Advisory Circulars AC 43.13-1B and AC 43.13-2B where applicable.
2.2 Installation Materials
The GTX 330 is available under the following part numbers:
2.2.1 Configurations Available
Table 2-1 Available Configurations
Model
Catalog Part
Number
Unit Part
Number
Diversity
Extended
Squitter
(ES)
Front
Panel
Color
Install Kit/
Docs*
TSO Class
GTX 330 010-00230-00 011-00455-00 No No Black No 2A1 121 010
GTX 330 010-00230-01 011-00455-00 No No Black Yes 2A1 121 010
GTX 330 010-00230-20 011-00455-20 No No Gray No 2A1 121 010
GTX 330 010-00230-21 011-00455-20 No No Gray Yes 2A1 121 010
GTX 330D 010-00293-00 011-00455-10 Yes No Black No 2A1 121 011
GTX 330D 010-00293-01 011-00455-10 Yes No Black Yes 2A1 121 011
GTX 330D 010-00293-20 011-00455-30 Yes No Gray No 2A1 121 011
GTX 330D 010-00293-21 011-00455-30 Yes No Gray Yes 2A1 121 011
GTX 330 010-00230-60 011-00455-60 No Yes Black No 2A1 121 010
GTX 330 010-00230-61 011-00455-60 No Yes Black Yes 2A1 121 010
GTX 330 010-00230-70 011-00455-80 No Yes Gray No 2A1 121 010
GTX 330 010-00230-71 011-00455-80 No Yes Gray Yes 2A1 121 010
GTX 330D 010-00293-60 011-00455-70 Yes Yes Black No 2A1 121 011
GTX 330D 010-00293-61 011-00455-70 Yes Yes Black Yes 2A1 121 011
GTX 330D 010-00293-70 011-00455-90 Yes Yes Gray No 2A1 121 011
GTX 330D 010-00293-71 011-00455-90 Yes Yes Gray Yes 2A1 121 011
*Documentation includes pilot’s guide and warranty registration card.

Garmin GTX 330 Specifications

General

Reply Frequencies	1090 MHz
Frequency Range	1090 MHz (reply)
Power Output	200 Watts peak
Dimensions	5.7 x 1.6 x 7.5 inches (145 x 41 x 191 mm)
Temperature Range	-20°C to +55°C
Operating Voltage	11-33 VDC
