GTX 330/330D Installation Manual 190-00207-02
Page 5-24 Rev. U
AIR DATA COMPUTER (ADC)
EFIS DISPLAY SYSTEM (EF/AD)
Table 5-24 Received Labels and Data from ADC
Label Data
203* Pressure Altitude (feet)
204 Barometric Corrected Altitude (feet)
205 Mach Number
206 Indicated Air Speed (knots)
210 True Air Speed (knots)
211 Total Air Temperature (degrees)
212 Vertical Speed (feet/min)
213 Static Air Temperature (degrees)
*If ADC W/ALT or EF/AD W/ALT format selected
Table 5-25 Received Labels and Data from EFIS Display
Label Data
100 Selected Course (degrees)
102 Selected Altitude (feet)
203* Pressure Altitude (feet)
204 Barometric Corrected Altitude (feet)
205 Mach Number
206 Indicated Air Speed (knots)
210 True Air Speed (knots)
211 Total Air Temperature (degrees)
212 Vertical Speed (feet/min)
213 Static Air Temperature (degrees)
234 Barometric Setting (hPa)
235 Barometric Setting (“Hg)
306 Joystick Lat
307 Joystick Lon
314 True Heading
320 Magnetic Heading (degrees)
325 Roll Angle
*If ADC W/ALT or EF/AD W/ALT format selected

Garmin GTX 330 Specifications

General

Reply Frequencies	1090 MHz
Frequency Range	1090 MHz (reply)
Power Output	200 Watts peak
Dimensions	5.7 x 1.6 x 7.5 inches (145 x 41 x 191 mm)
Temperature Range	-20°C to +55°C
Operating Voltage	11-33 VDC
