190-00207-02 GTX 330/330D Installation Manual
Rev. U Page 5-25
GPS/FMS NAVIGATION SYSTEM (GPS)
GARMIN DISPLAY
Table 5-26 Received Labels and Data from GPS/FMS
Label Data
102 Selected Altitude (feet)
310 Latitude (degrees)
311 Longitude (degrees)
312 Ground Speed (knots)
313 Track Angle (degrees)
Table 5-27 Received Labels and Data from Garmin Display
Label Data
261 Discrete Data
274 TAS Discrete
310 Latitude (degrees)
311 Longitude (degrees)
312 Ground Speed (knots)
313 Track Angle (degrees)
320 Magnetic Heading (degrees)

Garmin GTX 330 Specifications

General

Reply Frequencies	1090 MHz
Frequency Range	1090 MHz (reply)
Power Output	200 Watts peak
Dimensions	5.7 x 1.6 x 7.5 inches (145 x 41 x 191 mm)
Temperature Range	-20°C to +55°C
Operating Voltage	11-33 VDC
