Chapter 2: Installation
10 Kilsen KFP-CF Series Installation Manual
Connecting detectors
Connect detectors as shown in Figure 4 on page 9. Each zone circuit can support up
to 20 detectors.
Connecting manual call points
Connect manual call points in parallel, as shown in Figure 4 on page 9. Each zone
circuit can support up to 32 manual call points.
Manual call points must have a resistance installed in series with the normally open
(NO) contact to avoid a short-circuit and to allow the control panel to identify the
origin of the alarm (automatic or manual).
The resistance required will depend on the zone type as shown below.
Zone type Manual call point resistance
Mixed 100 Ω per 2 W
Manual 100 Ω to 470 Ω per 2 W
Note: The default zone detection settings for each operating mode can be found in
Appendix A “Configuration presets” on page 59. To change the zone detection setting,
see “Advanced configuration” on page 31.
Connecting inputs
Input functionality
Each control panel has two inputs, marked INPUT1 and INPUT2. These circuits are
connected as normally open and activated when closed.
The function of INPUT1 is defined by the panel operating mode. See Table 3 below.
Table 3: Input functionality for inputs 1 and 2
Operating mode INPUT1 INPUT2
EN 54-2 Remote reset Delays off
EN 54-2 Evacuation Remote reset Delays off
EN 54-2 Scandinavia Extended fire routing delay Delays off
BS 5839-1 Class change Delays off
NBN S21-100 Remote reset Delays off
NEN 2535 Fire routing inhibit delay Delays off
Note: INPUT1 is not used in two-zone control panels operating EN 54-2 Scandinavia mode.
Connecting inputs
Connect input switches to INPUT1 and INPUT2, as shown in Figure 4 on page 9. The
circuit should have a maximum resistance of 100 Ω (including any cable resistance).
