Chapter 3: Configuration and commissioning
Kilsen KFP-CF Series Installation Manual 39
Expansion module configuration
Add an expansion module
Use this menu, available from the basic or advanced configuration menus, to
configure the number of installed expansion modules. The default value is 00.
To add an expansion module:
1. Set the display as shown below, and then press Enter.
The Expansion I/O Fault/Disabled LED flashes quickly to indicate that the module
configuration menu is active.
2. Select a value using the value selection buttons (2 and 4).
3. Press Enter.
4. Save your changes.
The maximum number of expansion modules that can be installed is shown below.
Two- and four-zone control panels Up to two expansion modules
Eight-zone control panel Up to four expansion modules
Expansion module configuration
Expansion module labels
For configuration purposes expansion modules are labeled A and B (for two- and
four-zone control panels) or A, B, C, and D (for eight-zone control panels).
The label for a given module is defined by its position (left to right) in the control panel
cabinet,. The first expansion module installed is module A, the second B, etc.
See your expansion module installation sheet for installation instructions.
