Appendix A: Configuration presets
Kilsen KFP-CF Series Installation Manual 65
NEN 2535
Configuration presets for NEN 2535 are as follows.
Four- and eight-zone control panels
Code Zone EOL Sounder outputs Fire routing outputs Zone type
31 Passive 2 2 Odd zones:
Automatic
Even zones:
Manual
32 Passive, CleanMe
enabled
2 2 Odd zones:
Automatic
Even zones:
Manual
Note: CleanMe is not currently available for Kilsen detectors.
Additional configuration characteristics are shown below.
Default fire routing delay 1 minute
Default extended fire routing
delay
3 minutes
Default zone delay 0n
Start/Restart sounders Start sounders only if there is a fire alarm
Inputs and outputs are as follows.
INPUT1 Fire routing inhibit delay
INPUT2 Delays off
OUT1 Sounder circuit
OUT2 Sounder circuit
OUT3 Fire routing (automatic)
OUT4 Fire routing (manual)
