GE Kilsen KFP-CF4 User Manual

Chapter 2: Installation
Kilsen KFP-CF Series Installation Manual 11
Connecting outputs
Output functionality
Control panels have the following outputs:
• Two-zone control panels have two outputs, marked OUT1 and OUT2.
• Four- and eight-zone control panels have four outputs, marked OUT1, OUT2,
OUT3, and OUT4.
The function of each output is defined by the panel operating mode. See Table 4
below. All outputs are overload protected.
Table 4: Output functionality for outputs 1 to 4
Operating mode OUT1 OUT2 OUT3 OUT4
EN 54-2 Sounders Sounders Sounders Fire routing
EN 54-2 Evacuation Sounders Sounders Sounders Sounders
EN 54-2 Scandinavia Sounders Sounders Sounders Fire routing
BS 5839-1 Sounders Sounders Sounders Sounders
NBN S21-100 Evacuation
sounders
Evacuation
sounders
Warning
sounders
Warning
sounders
NEN 2535 Sounders Sounders Fire routing
(automatic)
Fire routing
(manual)
Output termination
All outputs require a 15 kΩ end-of-line resistor for termination. If an output is not
used, the 15 kΩ end-of-line resistor must be installed across the unused output
terminals.
Output polarity
All outputs are polarity sensitive. Observe polarity or install a 1N4007 diode to avoid
inverted activation issues.
Connecting the sounders
Depending on the operating mode, up to four sounder circuits can be connected. See
Table 4 above.
The sounder outputs are powered and supply −15 VDC in standby and +24 VDC
(nominal value) in alarm.
The maximum current consumption for each sounder circuit is shown
below.
Two- and four-zone control panels 250 mA
Eight-zone control panel 500 mA
The sounder outputs are supervised for short circuit and open circuit.
