7-12 Patient Data Module 2030047-001A
Field Replaceable Units
7. Licensing information must be re-entered. Contact GE technical support and
provide the Patient Data Module serial number and MAC address to proceed. See
the “How to Reach Us...” page included with this manual for contact information.
Go to Licensing on page 4-9 for instructions on entering the new activation code.
8. Manufacturer’s serial number must be re-entered. Go to Asset Settings on page
4-8 for instructions on entering the manufacturer’s serial number.
9. Go to the Solar 8000M/i patient monitor service manual and complete checkout
procedures.
NBP hose, coupling and elbow
1. Remove the top housing and main board per above steps.
2. Disconnect the front panel connector.
477A
3. Disconnect the main board flex pump connector.
4. Hold flex out of the way and disconnect the NBP hose from the coupling.
5. Remove hose from the manifold.
NOTE
When reassembling, slide hose all the way onto the manifold fitting so that
the hose lays flat.
6. Go to the Solar 8000M/i patient monitor service manual and complete checkout
procedures.
Front panel
connector
Main board flex pump
connector
NBP hose
and coupling
NBP hose at
manifold
