Appendix A–Technical Specifications
2030047-001A Patient Data Module A-7
Non-invasive blood pressure
Output specifications
Frequency response:
Zero balance range:
Zero balance accuracy:
Accuracy:
Displayed frequency
response:
Display scale selections:
Analog output:
Alarms:
Alarm range:
dc to 40 Hz (+0/-3 dB)
±150 mmHg
±1 mmHg
±2% or ±1 mmHg, which ever is greater (exclusive of
transducer)
0 to 12 Hz or 0 to 40 Hz (-3dB) user-selectable
0-30, 0-40, 0-60, 0-100, 0-160, 0-200, 0-300 mmHg
1 V/100 mmHg
User selectable upper and lower limits for systolic, diastolic,
and mean pressures
-99 to 350 mmHg
Measurement technique: Oscillometric
Displayed parameters: Systolic, diastolic, and mean pressures, pulse rate, time of
last measurement
Measurement modes: Manual, Auto, and Stat
Heart rate detection Adult, pediatric and neonate: 30 to 240 beats per minute
Total cycle time: 20 to 40 seconds typical (dependent on heart rate and motion
artifact)
