A-6 Patient Data Module 2030047-001A
Appendix A–Technical Specifications
Invasive blood pressure
Number of channels: Up to 4 (with appropriate cables)
Transducer sites, site name
and displayed values:
arterial (ART): systolic, diastolic, mean and rate
femoral (FEM): systolic, diastolic, mean and rate
pulmonary artery (PA): systolic, diastolic and mean
central venous pressure (CVP): mean
left atrial (LA): mean
right atrial (RA): mean
intracranial pressure (ICP): mean
umbilical artery (UAC): systolic, diastolic, mean and rate
umbilical vein (UVC): mean
special pressure (SP): mean
Transducer requirements Transducers meeting the following specifications can be
used, however, have not been evaluated by UL.
NOTE
Note: UL Classification covers the following invasive
blood pressure transducers:
 Utah, Deltran IV CPT-400
 Edwards, PX600
 Bekton Dikinson, P23XL-1
 Abbot, 42582-08
Accuracy: ±2% or ±1 mmHg, whichever is greater (exclusive of
transducer)
±2% or ±3 mmHg, whichever is greater (exclusive of Patient
Data Module)
Over pressure rating: 500 kPa (4000 mmHg) above atmospheric pressure (all
except catheter tip transducers)
Under pressure rating: 50 kPa (400 mmHg) below atmospheric pressure (all except
catheter tip transducers)
Excitation voltage:
Transducer output:
±2.5 V dc ±0.1%
50 μV/V/cm Hg
Input specifications
Range:
Offset:
-25 mmHg to 349 mmHg
±150 mmHg
