GE Healthcare Senographe DS Acquisition System
Revision 1 Operator Manual 5307907-3-S-1EN
Specifications
17-specs.fm Page no. 203 Chapter 17
3 Ambient Conditions
3-1 Operational ambient conditions
• Humidity: 10% min., 80% max.
• Temperature: 15°C (59°F) min., 35°C (95°F) max.
• Atmospheric pressure: 700 hPa min., 1060 hPa max.
3-2 Transport and storage ambient conditions
• Humidity: 10% min., 50% max.
95% max. may be tolerated for no longer than two weeks.
• Temperature: + 10°C (50°F) min., 25°C (77°F) max.
A wider range of -10°C (14°F), min. 50°C (122°F) max. can be tolerated for no longer than one day.
• Atmospheric pressure: 500 hPa min., 1060 hPa max.
3-3 Ambient light level
Senographe DS monitors are adjusted for use in light levels up to 50 lux.
4 Tube information
Tube Cooling Curves and other tube-specific technical parameters can be found in the Tube Product
Data document, part no. 2281990-100, included with the system documentation.
5 Dimensions and Weights
Component Dimensions in mm (inches) Weight
Depth Width Height kg (lbs)
Gantry 1273 (50.1) min. 616 (24.25)
max. 1842 (72.5)
min. 1930 (76)
max. 2626 (103.4)
410 (904)
Generator cabinet 640 (25.2)436 (17.2) 1330 (52.4)175 (386)
Control station with radiation
shield, monitor, and X-ray console
400 (15.75)710 (28) 2225 (87.6)210 (463)
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
