Diagnostics/Troubleshooting
7-34 Vivid T9/Vivid T8 – Basic Service Manual
5795591-100 English Rev. 3
7-4-5-13 Connected Probes
Connected Probes shows probes connected to the Vivid T9/
Vivid T8 . The order on the user interface is top down matching
the left-to-right order on the Vivid T9/Vivid T8 .
The information on Connected Probes is available to all service
class licenses.
To access Connected Probes, navigate to Utility > Service >
Home.
Figure 7-18. Connected Probes
This table shows all the elements available on Connected
Probes with descriptions.
For more information, see:7-4-5 ‘Home’ on page 7-15
Table 7-9: Connected Probes
Element DESCRIPTION
Active Probe Temperature (Celsius) When available, temperature of the active probe.
Not all probes report temperature. The most common probe
to report temperature is the TEE probe.
Probe Name Name of the probe connected to the Vivid T9/Vivid T8 .
Probe ID Identifier of the probe connected to the Vivid T9/Vivid T8 .
Serial Number Serial number of the probe connected to the Vivid T9/Vivid
T8 . If the serial number of the probe is not available, then N/
A displays.
Status Statuses of the probe connected to the Vivid T9/Vivid T8 .
Valid values are:
• Active
• Non Active
