3.3.2 Illustration of Xcellerex XDUO mixer
Introduction
The following illustrations show a full configuration of a jacketed 500 L XDUO mixer. The
configuration of each mixer may vary according to the selected optional features.
Front view
2
3
4
5
6
7
8 9
10
11
12
131
FunctionPart
I/O Cabinet1
Base pump2
Acid pump3
60 Xcellerex XDM 50-1000, XDUO 100-1000 mixers Operating Instructions 29251615 AD
3 System description
3.3 Xcellerex XDUO mixer system description
3.3.2 Illustration of Xcellerex XDUO mixer
