ADL500 • Quick installation guide - Specifications and connection 13
4.1 Environmental Conditions
Installation location ____________________ Pollution degree 2 or lower (free from direct sunligth, vibration, dust, corrosive or
inflammable gases, fog, vapour oil and dripped water, avoid saline environment)
Installation altitude ____________________ Max 2000m (6562 feet) above sea level. With 1.2% reduction in output current for every
100 m starting from 1000 m.
Mechanical conditions for installation _____ Vibrational stress: EN 61800-2 Class 3M1
Operating temperature _________________ ADL550: -10…+50°C (32°…122°F) without derating
ADL530, ADL510: -10…+40°C (+32…104°F) without derating
ADL530, ADL510: +40 ... +50°C (+104 … 122°F) with 1% derating every °C starting
from 40°C and up to 50°C. .
Air humidity (operating) _________________ from 5 % to 85 % and from 1 g/m
3
to 25 g/m
3
with no humidity (or condensation)
Air pressure (operating) _________________ from 70 to 106 kPa
Storage ______________________________ CEI EN 61800-2 Class 1K4, CEI EN 61800-2 Class 1K3
Maximum period of inactivity ___________ 12 months
4.2 Standards
Climatic conditions ____________________ EN 60721-3-3
Electrical safety _______________________ EN 61800-5-1, ASME17.5/CSA B44.1, UL840 degree of pollution 2
EMC compatibility _____________________ EN 12015 (with integrated filter), EN 12016 (Kit Power Shield recommended), IEC/EN 61800-3
Protection degree______________________ IP20
Approvals ____________________________
,
EC Directive __________________________ LVD 2014/35/EU, EMC 2014/30/EU, Lift 2014/33/EU, RoHS 2011/65/EU, EN 50581:2012
Other elevator standards _______________ EN 81-20, EN 81-50
4.3 Control modes
Motor control modes ___________________ Open loop scalar V-f control for IM motors (OL-VF)
Closed loop field-oriented control for IM motors (FOC-IM)
Closed-loop field-oriented control for permanent magnet synchronous motors (FOC-PMSM)
4.4 Precision
4.4.1 Speed control
Speed control precision __________________ Flux vector CL control (FOC) with feedback: 0.01 % motor rated speed
Open loop scalar V-f control (OL-VF) : ± 60 % rated slip of motor
4.4.2 Speed control limits
Speed range (*) ________________________ ± 32000 rpm
Speed format (*) _______________________ 32 bit
Frequency range _______________________ ± 2000 Hz
Max frequency ________________________ Flux vector CL control with feedback and brushless: 300Hz, FVOL: 150 Hz, VF: 600 Hz
Min frequency ________________________ 0 Hz
(*) referred to Full scale speed, PAR:680.
