ADL500 • Quick installation guide - Specifications and connection 29
The ADL550/530/510-...-F-.. series of inverters are equipped with an internal EMI able to guarantee the
Compliance with these requirements means the drive can be incorporated into lift systems built to EN 12015.
7.2.7 Connection of AC and DC chokes (optional)
(For three-phase ADL500 only). The drive can use both a three-phase choke on the AC power line and, for 1040 ...
2150 sizes only, a DC choke between terminals C1 and C.
Refer to chapter "5.2 Input chokes" on page 18 for the recommended connections.
If no DC choke is used on 1040 ... 2150 sizes, terminals C1 and C must be bridged.
If no DC choke is used, terminals C1 and C must be bridged (sizes 1-2).
