ADL500 • Quick installation guide - Specifications and connection 81
10.2 Speed fbk loss alarm according to the type of feedback
Note ! For the correct interpretation of the cause of the alarm trigger, it is necessary to transform the hex code indicated in parameter 15.13 SpdFbkLoss code,
PAR 2172 , in the corresponding binary and verify in the encoder table that the active bits and related description are used.
Example with encoder Endat:
PAR 2172 = A0H (hex value)
In the table "Speed fbk loss [22] alarm with absolute encoder EnDat" A0 is not indicated in the value column.
A0 should be contemplated as a bitword with meaning A0 -> 10100000 -> bit 5 and bit 7 . The following causes simultaneously intervene:
- Bit 5 = 20H Cause: the SSI signal interferences cause an error in the CKS or parity.
- Bit 7 = 80H Cause: The encoder has detected an incorrect operation and communicates it to the converter through the Error bit. Bits 16..31 present the
type of incorrect encoder operation detected.
The value is displayed in hexadecimal format on the optional and standard keypad.
 Speed fbk loss [22] alarm with digital incremental encoder
Bit Value Name Description
0 0x01 CHA Cause: no impulses or disturbance on incremental channel A.
Solution: Check the connection of the encoder-drive channel A, check the connection of the screen, check the encoder supply voltage, check parameter
2102 Encoder supply, check parameter 2104 Encoder input config.
1 0x02 CHB Cause: no impulses or disturbance on incremental channel B.
Solution: Check the connection of the encoder-drive channel B, check the connection of the screen, check the encoder supply voltage, check parameter
2102 Encoder supply, check parameter 2104 Encoder input config.
2 0x04 CHZ Cause: no impulses or disturbance on incremental channel Z.
Solution: Check the connection of the encoder-drive channel Z, check the connection of the screen, check the encoder supply voltage, check parameter
2102 Encoder supply, check parameter 2104 Encoder input config, check parameter 2110 Encoder signal check
 Speed fbk loss [22] alarm with sinusoidal incremental encoder
Bit Value Name Description
3 0x08 MOD_INCR Cause: voltage level not correct or disturbance on signals of incremental channels A-B.
Solution: Check the connection of the encoder-drive channels A-B, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply, check parameter 2108 Encoder signal Vpp.
 Speed fbk loss [22] alarm with SinCos encoder
Bit Value Name Description
3 0x08 MOD_INCR Cause: voltage level not correct or disturbance on signals of incremental channels A-B.
Solution: Check the connection of the the encoder-drive channels A-B, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply, check parameter 2108 Encoder signal Vpp.
4 0x10 MOD_ABS Cause: voltage level not correct or disturbance on signals of absolute SinCos channels.
Solution: Check the connection of the the encoder-drive channels A-B, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply, check parameter 2108 Encoder signal Vpp.
 Speed fbk loss [22] alarm with SSI absolute encoder
Bit Value Name Description
3 0x08 MOD_INCR Cause: voltage level not correct or disturbance on signals of incremental channels A-B.
Solution: Check the connection of the the encoder-drive channels A-B, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply, check parameter 2108 Encoder signal Vpp.
5 0x20 CRC_CKS_P Cause: SSI signals not present or disturbed.
Solution: Check the connection of the clock and encoder-drive data, check the connection of the screen, check the encoder supply voltage, check param-
eter 2102 Encoder supply, check parameter 7106 BiSS N bit ST and 7108 BiSS N bit MT.
8 0x100 Setup error Cause: An error occurred during setup.
Solution: Check the connection of the clock and encoder-drive data, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply, check parameter 7106 BiSS N bit ST and 7108 BiSS N bit MT.
