3-3032-0253-EN Rev 3
Safety
Laser Radiation Hazard
Use of controls or adjustments, or performance of procedures other than
those specified in this manual, may result in hazardous laser radiation
exposure.
This equipment is designed in accordance with IEC 60825-1:2001. Although compliant with
laser safety rules, it is good practice for the operator to avoid exposing anyone’s eyes to laser
beams.
The position of laser sources are identified by means of the following warning labels (black on
yellow).
The laser for the lighting of the midsagittal plane (vertical laser beam) is positioned on the
column above the rotating imaging assembly.
Two lasers for the lighting of the Frankfurt plane (horizontal laser beam) and the laser beam that
is aligned with the lateral incisor roots (cuspid laser beam) are positioned to the left of the
sensor.
