Gendex Orthoralix 8500 DDE User Manual

A-1032-0253-EN Rev 3
Appendix
A
Technical Data
Orthoralix 8500 DDE Tubehead - 110-0184G2
Orthoralix 8500 DDE Column and Imaging Assembly - 110-0234G1, 110-
0234G3
Collimator - 112-1143G1
Power supply 120V AC or 230V AC nominal
Frequency 50-60 Hz
Max. line current rating 8.5A at 230V, 13.5A at 120V for 80kV and 10mA
Nominal line current (idle) stand-by ( 1.1A at 230V, 2.0A at 120V
High voltage waveform true DC, via square-wave output electronic power
converter (50kHz) and voltage multiplier/rectifier
HVDC Power Supply A regulated output switch-mode power supply.
Outputs are independent of line voltage
fluctuation.
60 kV to 80 kV, in 2 kV steps max. tolerance from nominal value ±5%
4 mA to 10 mA, steps 4,6,8,10 max. tolerance from nominal value ±5%
Max. deviation of exposure time + 2%
Tube Type See Product Data Sheet on Installation Manual
Tube Housing See Product Data Sheet on Installation Manual
Duty Factor 1:20
Focal Spot Indicators 3 raised indicators on Tubehead Cover
Output Dose Rate approx. average 1.2 mGy/s at 70 kV, 8 mA,
500 mm.
Leakage radiation from the tubehead: less than 0.25 mGy/ hour at 1 m in any direction
Leakage Technique Factors 80kV at 0.5mAs
Weight 245 lbs., 115 kg
