Gendex Orthoralix 8500 DDE User Manual

B-1032-0253-EN Rev 3
Appendix
B
Technique Factors
Modality: Pan
Total exposure Time (seconds) Total Cycle Time  (seconds) Magnification Movement range of  the focal layer,  related to the jaw  morphology (mm)
Preset technique
factors
mA Small patient (kV) Medium patient (kV) Large patient (kV)
Standard panoramic
12 24 1.25 0-14 (ref.7) 68 72 76 6
Child panoramic
11 24 1.25 0-14 (ref.7) 62 66 70 6
Lateral TMJ 
(open/close mouth)
8 27 1.23 ---------------- 66 70 74 6
Frontal TMJ
6 27 1.64 ---------------- 68 72 76 6
