Orthoralix 8500 DDE
032-0253-EN Rev 36-10
These icons indicate different system conditions:
GX Driver Icon
When the Gendex driver is installed correctly, the Gx icon is shown in the
system tray.
Right-click this icon to display a menu for viewing and modifying data and
parameters common to all the Gendex imaging system products.
Double-click this icon to open a configuration panel which contains
information about the operation of the electronics, the software version, and
the characteristics of the CCD sensor.
Icon Status
Large red X:
- Faulty hardware condition
- Sensor calibration required
Small red X: CCD sensor not present
Magnifying glass: Connection problem
somewhere in the system
Red: Orthoralix 8500 DDE is not present on the
network
Yellow X: Computer/networking device
connected but does not have control
