Gree GMV-ND22C/A-T Service Manual

GREE GMV5 INDOOR UNIT SERVICE MANUAL
11
No.
Description
Options
4
Function code
R – pure heat pump/ all heat exchanger with cooling function
L-cooling only unit
X-fresh air
W- double thermal source
Q – heat recovery
Null – electric heating defaulted
5
Cooling capacity/air volume
code
Indoor unit: norminal cooling capacity /100(W)
All heat exchanger: air volume /100(m
3
/h)
6
Unit type
PL- low static pressure duct type unit;
P-standard static pressure duct type unit
PH- high static pressure duct type unit;
PB-slim type duct type unit
T- 4-way cassete unit;
TX – cassete unit with small panel (4-way air supply)
A-Air handler
；
TD-one-way cassette unit;
TS- two-way cassette unit;
ZD- floor ceiling unit;
ZK- combine unit
C-console unit;
G- wall-mounted unit
；
L- Floor Standing unit
U-AHU-KITunit
ZA- Concealed Floor Standing unit
7
With water pump or not
With water pump –S
(S is not displayed for the cassette unit with water pump)
8
Design serial No.
Nominate by A,B,C or expand it by 1, 2, 3…
9
Power
D - 220V~,60Hz; 208-230V~,60Hz; 220-240V~,60HZ; 208/230V~,60Hz;
M - 380V 3N~, 50Hz;400V 3N~,50Hz; 380-415V 3N~,50Hz;
K - 220-240V~,50Hz; 230-240V~,50Hz;
T - 208-230V~,60Hz & 220-240V~,50Hz
Note:
① If there’s “(X+figure)”at the end of model, it indicates the fresh air handler. X——fresh air; Figure
(take one decimal fraction) —— air volume (m
3
/h) ×10-3. Eg: (X2.0).
② DC inverter fresh air processing indoor, airflow volume ranging from 2000m³/h to 3500m³/h are
available, there’s not “(X+figure)”at the end of model.
3 Specifications
3.1 Floor Standing Type
Model
GMV-ND100L/A-T
GMV-ND140L/A-T
Cooling capacity
kW
10.0
14.0
Heating capacity
kW
11.0
15.0
Circulating air volume
m
3
/h
1870
1870
Noise
dB(A)
50
50
Power supply
220-240V~50Hz
208-230V~60Hz
220-240V~50Hz
208-230V~60Hz
Rated power input
Cooling
kW
0.2
0.2
Heating
kW
0.2
0.2
Unit Dimensions (mm)(W×D×H)
1850×580×400
Package Dimensions (mm)(W×D×H)
2083×738×545
Suitable climite
T1
T1
Connection pipe
Gas
mm
Φ15.9
Φ15.9
