Gree GMV-ND22C/A-T Service Manual

GREE GMV5 INDOOR UNIT SERVICE MANUAL
44
Model(Combined)
GMV-N560U/A-
T+GMV-N140U/A-T
GMV-N560U/A-
T+GMV-N280U/A-T
GMV-N560U/A-
T+GMV-N560U/A-T
(W×D×H)
Control box
mm
(334×284×111)×2
(334×284×111)×2
(334×284×111)×2
Net weight
kg
11.8+8.6
11.8+8.6
11.8+11.8
3.16 Concealed Floor Standing Type
Model
GMV-
ND22ZA/A-
T
GMV-
ND28ZA/A-
T
GMV-
ND36ZA/A-
T
GMV-
ND45ZA/A-
T
GMV-
ND56ZA/A-
T
GMV-
ND63ZA/A-
T
GMV-
ND71ZA/A-
T
Horse Power
HP
1
1
1.5
2
2
2.5
3
Cooling capacity
kW
2.2
2.8
3.6
4.5
5.6
6.3
7.1
Heating capacity
kW
2.5
3.2
4.0
5.0
6.3
7.1
8.0
Air Volume
m
3
/h
450
450
550
650
900
900
1100
External Static Pressure
Pa
10/0~40
10/0~40
10/0~40
15/0~60
15/0~60
15/0~60
15/0~60
Cooling power input
W
35
35
43
45
80
80
90
Cooling current input
A
0.18
0.18
0.22
0.23
0.41
0.41
0.46
Heating power input
W
35
35
43
45
80
80
90
Heating current input
A
0.18
0.18
0.22
0.23
0.41
0.41
0.46
*Minimum line current
A
0.2
0.2
0.3
0.3
0.5
0.5
0.5
*Maximum fuse current
A
6
6
6
6
6
6
6
Sound pressure level
dB(A)
30
30
33
33
35
35
37
Power supply**
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Pipe
diameter
Liquid pipe
mm
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ9.52
Φ9.52
Φ9.52
Gas pipe
mm
Φ9.52
Φ9.52
Φ12.7
Φ12.7
Φ15.9
Φ15.9
Φ15.9
Drain pipe
External
diameter ×
thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Dimensions
W×D×H
mm
700×615
×200
700×615
×200
700×615
×200
900×615
×200
1100×615
×200
1100×615
×200
1100×615
×200
Net weight
kg
23
23
23
27
32
32
32
Notes:
① Rated cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB; connection
pipe length: 5m, without height drop between units.
② Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection
pipe length: 5m, without height drop between units.
③ In the column of “Unit external static pressure”: The figure before “/” indicates the default external
static pressure of unit before delivery, and the figures after indicate the adjustable static pressure
range of unit.
