GREE GMV5 INDOOR UNIT SERVICE MANUAL
25
range of unit.
3.11 Air Handler type Indoor Unit
Model
GMV-
NR71A/A-D
GMV-
NR90A/A-D
GMV-
NR100A/A-D
GMV-
NR112A/A-D
GMV-
NR140A/A-D
Horse Power
HP
2.5
3.0
3.5
4.0
5.0
Cooling capacity
kW
7.1
9.0
10.0
11.2
14.0
Heating capacity
kW
8.0
10.0
11.0
12.5
15.0
Air volume
m
3
/h
1600
1700
1900
2250
2400
Cooling power input
W
215
270
370
430
550
Cooling current input
A
1.10
1.35
2.00
2.00
2.50
Heating power input
W
215
270
370
430
550
Heating current input
A
0.4
0.4
0.4
0.5
0.5
*Minimum line current
A
1.10
1.35
2.00
2.00
2.50
*Maximum fuse current
A
6
6
6
6
6
Sound pressure level
dB(A)
50
51
52
52
55
Power supply*
208-230V 1 phase ~60Hz
Piping
interface
Liquid pipe
mm
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Gas pipe
mm
Φ15.9
Φ15.9
Φ15.9
Φ15.9
Φ15.9
Drain pipe
External diameter
×Thickness
mm
Φ19×2.5
Φ19×2.5
Φ19×2.5
Φ19×2.5
Φ19×2.5
Main body
dimensions
W×D×H
mm
460×540
×1105
460×540
×1105
540×540
×1224
540×540
×1224
630×540
×1224
Panel
dimensions
W×D×H
mm
517×620×1170
517×620×1170
597×620×1289
597×620×1289
687×621×1295
Net weight
Main body
kg
54
57
57
68
78
Notes:
① Rated cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB; connection
pipe length: 5 m, without height drop between units.
② Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection
pipe length: 5 m, without height drop between units.
