GREE GMV5 INDOOR UNIT SERVICE MANUAL
41
3.14 Super High Static Pressure Duct Type Indoor Unit
Model
GMV-
ND22PHS/B
-T
GMV-
ND25PHS/B
-T
GMV-
ND28PHS/B
-T
GMV-
ND32PHS/B
-T
GMV-
ND36PHS/B
-T
GMV-
ND40PHS/B
-T
Horse Power
HP
1
1
1.5
2
2
2
Cooling capacity
kW
2.2
2.5
2.8
3.2
3.6
4
Heating capacity
kW
2.5
2.8
3.2
3.6
4
4.5
Air Volume
m
3
/h
550
550
550
600
600
850
External Static Pressure
Pa
60/0~150
60/0~150
60/0~150
60/0~150
60/0~150
60/0~150
Cooling power input
W
55
55
55
65
65
85
Cooling current input
A
0.5
0.5
0.5
0.5
0.5
0.5
Heating power input
W
55
55
55
65
65
85
Heating current input
A
0.5
0.5
0.5
0.5
0.5
0.5
*Minimum line current
A
0.375
0.375
0.375
0.375
0.375
0.5
*Maximum fuse current
A
6
6
6
6
6
6
Sound pressure level
dB(A)
33
33
33
33
33
36
Power supply**
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Pipe
diameter
Liquid pipe
mm
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Gas pipe
mm
Φ9.52
Φ9.52
Φ9.52
Φ12.7
Φ12.7
Φ12.7
Drain pipe
External diameter
×thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Dimensions
W×H
mm
700×300
×700
700×300
×700
700×300
×700
700×300
×700
700×300
×700
700×300
×700
Net weight
kg
32
32
32
32
32
34
Model
GMV-
ND45PHS/B-
T
GMV-
ND50PHS/
B-T
GMV-
ND56PHS/
B-T
GMV-
ND63PHS/
B-T
GMV-
ND71PHS/
B-T
GMV-
ND80PHS/
B-T
Horse Power
HP
2
2
2
3
3
3
Cooling capacity
kW
4.5
5.0
5.6
6.3
7.1
8.0
Heating capacity
kW
5.0
5.6
6.3
7.1
8.0
9.0
Air Volume
m
3
/h
850
850
1000
1000
1250
1250
External Static Pressure
Pa
60/0~150
60/0~150
90/0~200
90/0~200
90/0~200
90/0~200
Cooling power input
W
85
85
90
90
100
100
Cooling current input
A
0.5
0.5
0.8
0.8
0.8
0.8
Heating power input
W
85
85
90
90
100
100
Heating current input
A
0.5
0.5
0.8
0.8
0.8
0.8
*Minimum line current
A
0.5
0.5
0.5
0.5
0.5
0.5
*Maximum fuse current
A
6
6
6
6
6
6
Sound pressure level
dB(A)
36
36
37
37
38
38
Power supply**
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Pipe
diameter
Liquid pipe
mm
Φ6.35
Φ6.35
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Gas pipe
mm
Φ12.7
Φ12.7
Φ15.9
Φ15.9
Φ15.9
Φ15.9
Drain pipe
External diameter
×thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Dimensions
W×H
mm
700×300×700
700×300×7
00
700×300×1
000
700×300×1
000
700×300×1
000
700×300×1
000
Net weight
kg
34
34
43
43
43
43
