Gree GMV-ND22C/A-T Service Manual

GREE GMV5 INDOOR UNIT SERVICE MANUAL
17
Model
GMV-
ND22T/B-T
GMV-
ND28T/B-T
GMV-
ND36T/B-T
GMV-
ND45T/B-T
GMV-
ND50T/B-T
GMV-
ND56T/B-T
Heating current input
A
0.4
0.4
0.4
0.5
0.5
0.5
*Minimum line current
A
0.5
0.5
0.5
0.63
0.63
0.63
*Maximum fuse current
A
6
6
6
6
6
6
Sound pressure level
dB(A)
41
41
41
45
45
45
Power supply**
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Piping
interface
Liquid pipe
mm
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ9.52
Φ9.52
Gas pipe
mm
Φ9.52
Φ9.52
Φ12.7
Φ12.7
Φ12.7
Φ15.9
Drain pipe
External
diameter
×Thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Main body
dimensions
W×D×H
mm
596×596×240
596×596×240
596×596×240
596×596×240
596×596×240
596×596×240
Panel
dimensions
W×D×H
mm
670×670×50
670×670×50
670×670×50
670×670×50
670×670×50
670×670×50
Net weight
Main body
kg
20.5
20.5
20.5
20.5
20.5
20.5
Panel
kg
3.5
3.5
3.5
3.5
3.5
3.5
Notes:
① Rated cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB; connection
pipe length: 5 m, without height drop between units.
② Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection
pipe length: 5 m, without height drop between units.
3.6 2-way Cassette Type
Model
GMV-
ND28TS/A-
T
GMV-
ND36TS/A-
T
GMV-
ND45TS/A-
T
GMV-
ND50TS/A-
T
GMV-
ND56TS/A-
T
GMV-
ND63TS/A-
T
GMV-
ND71TS/A-
T
Horse Power
HP
1
1.5
2
2
2
2
2.5
Cooling capacity
kW
2.8
3.6
4.5
5.0
5.6
6.3
7.1
Heating capacity
kW
3.2
4.0
5.0
5.6
6.3
7.1
8.0
Air volume
m
3
/h
830
830
830
830
1100
1100
1100
Cooling power input
W
55
55
55
55
103
103
103
Cooling current input
A
0.4
0.4
0.4
0.4
0.7
0.7
0.7
Heating power input
W
55
55
55
55
103
103
103
Heating current input
A
0.4
0.4
0.4
0.4
0.7
0.7
0.7
*Minimum line current
A
0.5
0.5
0.5
0.5
0.9
0.9
0.9
*Maximum fuse current
A
6
6
6
6
6
6
6
Sound pressure level
dB(A)
35
35
35
35
39
39
39
