GREE GMV5 INDOOR UNIT SERVICE MANUAL
20
Model
GMV-
ND90ZD/A-T
GMV-
ND112ZD/A-T
GMV-
ND125ZD/A-T
GMV-
ND140ZD/A-T
GMV-
ND160ZD/A-T
Heating capacity
kW
10.0
12.5
14.0
16.0
18.0
Air volume
m
3
/h
1600
2000
2000
2000
2300
Cooling power input
W
140
160
160
160
200
Cooling current input
A
1.1
1.4
1.4
1.4
1.9
Heating power input
W
140
160
160
160
200
Heating current input
A
1.1
1.4
1.4
1.4
1.9
*Minimum line current
A
1.17
1.5
1.5
1.5
2
*Maximum fuse current
A
6
6
6
6
6
Sound pressure level
dB(A)
50
52
52
52
52
Power supply
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Piping
interface
Liquid pipe
mm
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Gas pipe
mm
Φ15.9
Φ15.9
Φ15.9
Φ15.9
Φ19.05
Drain pipe
External
diameter
×thickness
mm
Φ17×1.75
Φ17×1.75
Φ17×1.75
Φ17×1.75
Φ17×1.75
Dimensions
W×D×H
mm
1420×700×245
1700×700×245
1700×700×245
1700×700×245
1700×700×245
Net weight
kg
50
60
60
60
60
Notes:
① Rated Cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB; connection
pipe length: 5 m, without height drop between units.
② Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection
pipe length: 5 m, without height drop between units.
3.9 Fresh air Processing Unit
AC Inverter Fresh Air Processing Indoor
Model
GMV-
NX140P/A
(X1.2)-K
GMV-
NX224P/A
(X2.0) -M
GMV-
NX280P/A
(X2.5) -M
GMV-
NX280P/A
(X3.0) -M
GMV-
NX450P/A
(X4.0) -M
Horse Power
HP
5
8
10
10
16
Cooling capacity
kW
14
22.4
28
28
45
Heating capacity
kW
10
16
20
20
32
Air volume
m
3
/h
1200
2000
2500
3000
4000
Cooling power input
W
360
740
760
1060
1240
Static pressure (Pa)
Standard
150
200
200
200
200
Optional
200
300
300
300
300
Cooling current input
A
1.65
2.10
2.40
2.47
3.40
Heating power input
W
360
740
760
1060
1240
Heating current input
A
1.65
2.10
2.40
2.47
3.40
Minimum line current
A
2.1
2.6
3.0
3.1
4.3
