10
GB 05 02 01
Sprayer setup
FF
FF
F
ixix
ixix
ix
ed dred dr
ed dred dr
ed dr
aa
aa
a
wbarwbar
wbarwbar
wbar
Make sure the drawbar points straight ahead from its
position on the trailer. If not, the two turn buckles A can
be adjusted till the drawbar is centred.
STEERING drSTEERING dr
STEERING drSTEERING dr
STEERING dr
aa
aa
a
wbarwbar
wbarwbar
wbar
Transport lock (if fitted)
The transport lock is a safeguard that will keep the
drawbar in a centred position in case of hydraulic leak-
age during transport on public roads.
The transport lock is fixed by linch pins.
If necessary, the transport lock can be adjusted by
turning the turnbuckle.
SELF TRASELF TRA
SELF TRASELF TRA
SELF TRA
CK fCK f
CK fCK f
CK f
or COMMANDER 2200/2800or COMMANDER 2200/2800
or COMMANDER 2200/2800or COMMANDER 2200/2800
or COMMANDER 2200/2800
SELF TRACK is connected as follows:
1. Attach the tractor lower links in the two mountings of
the SELF TRACK. Adjust the length of the drawbar if
necessary - to obtain the best tracking, choose the
setting where the distance X is equal to distance Y.
Secure with linch pins.
2. Attach safety chains to top link clevis. The chain will
prevent the transmission shaft from being damaged if
the lift arms are lowered too far. Adjust the chain
length so the chains are tight when the tractor P.T.O.
and pump shaft are in a horizontal line.
T251-0022
T251-0015
NOTE! If possible, lock the tractor hydraulic lever when
the lift arms are in the correct position to avoid the
sprayer weight resting on the stabiliser chains.
3. Tighten the lift arm stabiliser chains.
WARNING! Do not stand in the area around the
drawbar during manoeuvring.
AA
AA
A
UTUT
UTUT
UT
O TRAO TRA
O TRAO TRA
O TRA
CKCK
CKCK
CK
Please refer to separate instruction book.
Hose pacHose pac
Hose pacHose pac
Hose pac
kk
kk
k
aa
aa
a
gg
gg
g
e suppore suppor
e suppore suppor
e suppor
t t
t t
t
To prevent hoses and wiring from being damaged by the
tractor wheels, all hoses, cables and wires are held by
the hose bracket A fitted to the drawbar.
Check that the length of the hoses and cables are
sufficient by tight turns.
T251-0023
T251-0016
